Now maximize the ProSim-II Simulation Window Pa g e 1 of 7 Lo g ixPro Rela y Lo g ic Lab file://C:\Pro g ram%20Files\TheLearnin g Pit\Lo g ixPro\doc\nrl\intro-rl.html Just click on "OK" to accept the default TLP LogixPro selection. A dialog box will appear asking for you to select a Processor Type. If your program is not empty, then click on the File menu entry at the top of the screen and select "New" from the drop-down list. If this is the only rung visible then your program is currently empty. This is the End of Program rung and is always the last rung in any program. The program editing window should contain a single rung.
From the Simulations Menu at the top of the screen, Select the I/O Simulation and ensure that the User Instruction Bar shown above is visible.
LogixPro Relay Logic Introductory Lab RSLogix Relay Logic Instructions This exercise is designed to familiarize you with the operation of LogixPro and to step you through the process of creating, editing and testing simple PLC programs utilizing the Relay Logic Instructions supported by RSLogix.
